  • Oilless Clean Dry Air
  • Meets NFPA 99 Carbon Monoxide Monitor
  • Dew Point Monitor
  • Corrosion Resistant ASME Receiver Tank
  • UL Listed NEMA 12 Medical Control Panel
* Consult factory for triplex, quadplex, or larger systems
Unit of Measure

Financing

Approve Payments

 N/A Finance with Approve Payments

Specifications

Shipping Weight

 N/A 1630 Pound

Optional Equipment

 N/A Dual Desiccant Dryer System Fuseless Circuit Breaker Control Panel Sound Enclosure

Speed

 N/A 1250 rpm

Phase

 N/A 3

Power of Each Motor

 N/A 15 hp

Number of Motors

 N/A 2

Voltage

 N/A 208 V230 V460 V

Full Load Motor Current

 N/A 20.7 A41.4 A43 A

Tank

 N/A 200 gal

Flow at 100 Pound Per Square Inch (psi) Pressure

 N/A 108.4 ft³/min

Flow at 50 psig

 N/A 114.1 ft³/min

Features

Features

 N/A
  • Dual Refrigerated Dryer System
  • Medical Filter Package (Not Shown)
  • High Efficiency Motor
  • Low Pressure Alarm System
  • Modular Design
  • Electric Moisture Drain
  • Aftercooler and Drain Trap
  • 3 Year Pump Warranty
  • 1 Year System Warranty
