Airtech® oil-flooded, multi-vane vacuum pumps are single stage, air cooled and direct driven. This simple design ensures the reliability and the durability that is required in the vacuum industry.
Unit of Measure

Financing

Approve Payments

 N/A Finance with Approve Payments

Specifications

Motor Voltage

 N/A 208-230 V460 V

Power Supply Frequency

 N/A 50 Hz60 Hz

Inlet Size

 N/A 2 in. National Pipe Thread (NPT)

Outlet Size

 N/A 2 in NPT

Free Air Displacement at 60 Hz

 N/A 212 ft³/min

Motor Capacity at 60 Hz

 N/A 12 hp

Sound Level at 60 Hz

 N/A 76 dBA

End Vacuum - L

 N/A 0.5 Torr
Weight1 N/A 415 lb

Oil Quantity

 N/A 7 qt

Speed at 60 Hz

 N/A 1725 rpm

Standard Equipment

N/A

  • High performance carbon composite vanes
  • Oil level sight glass
  • Vibration isolators
  • Anti-suck back valve
  • Integral exhaust filters
  • TEFC high efficiency tri-voltage motor (208-230/460V 50/60)
  • Exhaust pressure gauge
  • Wire mesh inlet screen
  • Spin-on oil filter

Note

N/A Specifications are subject to change without notice.

  • 1 with motor
